. . . . . . . . . . . . . . . . . . . TransWorld Energy

Device 9-1 . . .

. . . Prototype Energy System for Brazil and Saudi Arabian Markets: Note the coils in pairs, left and right. Each pair produces 1000 Volts at 50 Amps; 8 pairs = 8000 Volts at 400 Amps when output to a Buss Bar. Dimensions are 14.5" High/16" Long/10" Wide. A milliwatt motor turns the magnetic shield shich separates the magnet pairs at their block; wall separation provides magnetic fluxing and useful electrical energy.
