Device 9-2 . .
.
. . . Prototype
Energy System for Brazil and Saudi Arabian Markets: Note the
coils in pairs, left and right. Each pair produces 1000 Volts
at 50 Amps; 8 pairs = 8000 Volts at 400 Amps when output to
a Buss Bar. Dimensions are 14.5" High/16" Long/10"
Wide. A milliwatt motor turns the magnetic shield shich separates
the magnet pairs at their block; wall separation provides
magnetic fluxing and useful electrical energy.
|
|
